It is suitable for welding low carbon steel structure, especially for welding thin plate steel with short discontinuous weld and requirement of smooth welding pass.
E6013 is a rutile type electrode. Can be welding by both AC & DC power source and can be applied in all-position. It have excellent welding performance as stable arc, little spatter, easy slag removal and restrick-ability etc.
Usually, it’s no need to re-dry the electrode before welding. When it was affected with damp, should be redried 150℃-170℃ for 0.5-1 hour.
WELDING POSITIONS: PA, PB, PC, PD, PE, PF
X-ray flaw detection: Ⅱ level
DEPOSIT COMPOSITION (Quality Score): %
| Items |
C |
Mn |
Si |
S |
P |
Ni |
Cr |
Mo |
V |
| Requirements |
≤0.10 |
0.32-0.55 |
≤0.30 |
≤0.030 |
≤0.035 |
≤0.30 |
≤0.20 |
≤0.30 |
≤0.08 |
| Typical Results |
0.08 |
0.37 |
0.18 |
0.020 |
0.025 |
0.030 |
0.035 |
0.005 |
0.004 |
| Items |
Tensile Strength Rm/MPa |
Yield Strength Rel/Rp0.2 MPa |
Elongation A/% |
Charpy V-Notch KV2(J)0℃ |
| Requirements |
440-560 |
≥355 |
≥22 |
≥47 |
| Typical Results |
500 |
430 |
27 |
80 |
TYPICAL OPERATING PROCEDURES: (AC,DC)
| Diameter (mm) |
2.0 |
2.5 |
3.2 |
4.0 |
5.0 |
| Current (A) |
40-70 |
50-90 |
80-130 |
150-200 |
180-240 |
Standard Packaging: 5kgs/box, 4boxes/carton, 20kgs/carton, 50cartons/pallet. 21-26MT per 1X20" FCL.
OEM/ODM: We support OEM/ODM and could make packaging according to your design, please contact us for detail discussion.
Frequently Asked Questions
Q: What type of welding is E6013 electrode best suited for?
A: It is ideal for welding low carbon steel structures, particularly thin plate steel requiring smooth passes and short, discontinuous welds.
Q: Can E6013 be used with an AC welder?
A: Yes, E6013 is a rutile type electrode that performs excellently with both AC and DC power sources.
Q: Do I need to dry the electrodes before use?
A: Generally, re-drying is not necessary. However, if the electrodes have been exposed to damp conditions, they should be dried at 150℃-170℃ for 30 to 60 minutes.
Q: What are the main welding characteristics of E6013?
A: It offers a stable arc, minimal spatter, easy slag removal, and excellent re-striking ability, making it very user-friendly.
Q: What welding positions can be used with this electrode?
A: It is an all-position electrode, suitable for PA, PB, PC, PD, PE, and PF positions.
Q: Do you offer customized packaging?
A: Yes, we provide full OEM and ODM support, allowing for packaging designs tailored to your specific requirements.
